Features

  1. Efficiency More than other Ordinary brands.
  2. Input & Output fully Protection.
  3. Minimum Noise ripple.
  4. Less than 0.1% Line regulation.
  5. Less than 3%Load regulation.
  6. Sustainable in worse input power condition.
  7. Short circuit protection.
  8. Surge voltage protection up to 3kv.
  9. Soft start System

Specifications

Operating Voltage - 230VAC / 50Hz (140VAC - 280VAC)

Model Voltage Range Current Cap. Wattage Enclosure Dimension
L X W X H
(mm)
SM2450TM 24VDC 5Amp. 120W Metal Body 153 X 76 X 45
SM12100TM 12VDC 10Amp. 120W Metal Body 153 X 76 X 45
